Stauff SP-160-E-05-B/4 Replaces the Stauff SP160E05B4
Stauff SP-160-E-05-B/4 Replaces the Stauff SP160E05B4
SP-160-E-05-B/4
Stauff
Stauff SP160E05B4
Stauff
Stauff SP160E05B4
Description
Replacement Filter Element for Pressure Filters Micron Rating: 5 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 95 Inner Diameter (mm): 55,7 Length (mm): 428 Sealing: NBR, β ratio >200
Brand:
Stauff
Regular price
€237,95
Unit price
per
1.71 kg
8421.99.90
Germany
1.82 kg
8421.99.90
France
1.6 kg
8421.99.90
United Kingdom
3.53 kg
8421.99.90
Italy
Description
Replacement Filter Element for Pressure Filters Micron Rating: 5 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 95 Inner Diameter (mm): 55,7 Length (mm): 428 Sealing: NBR, β ratio >200Specification
| Style | Pressure Filter |
| Efficiency 1 | 5µ @ β200 |
| Efficiency 2 | 7µ @ β1000 |
| Outer Diameter | 96.0 mm |
| Inner Diameter | 56.5 mm |
| Length | 429.0 mm |
| Media | Glass Fiber |
| Flow Direction | OUT-IN |
| Δ Collapse Pressure | 25 BAR |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
