Stauff SE-090-H-10-B/4 Replaces the Stauff SE090H10B4
Stauff SE-090-H-10-B/4 Replaces the Stauff SE090H10B4
SE-090-H-10-B/4
Stauff
Stauff SE090H10B4
Stauff
Stauff SE090H10B4
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 90,5 Inner Diameter (mm): 48,5 Length (mm): 164 Sealing: NBR, β ratio >200
Brand:
Stauff
Regular price
€244,95
Unit price
per
1.33 kg
8421.99.90
Germany
1.14 kg
8421.99.90
United Kingdom
1.14 kg
8421.99.90
Italy
1.14 kg
8421.99.90
France
1.38 kg
8421.29.80.90
United States
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 90,5 Inner Diameter (mm): 48,5 Length (mm): 164 Sealing: NBR, β ratio >200Specification
| Style | Pressure Filter |
| Efficiency 1 | 10µ @ β200 |
| Efficiency 2 | 12µ @ β1000 |
| Outer Diameter | 90.5 mm |
| Inner Diameter | 48.1 mm |
| Length | 162.0 mm |
| Media | Glass Fiber |
| Flow Direction | OUT-IN |
| Δ Collapse Pressure | 210 BAR |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
