Stauff SE-090-G-10-B/4 Replaces the Stauff SE090G10B4
Stauff SE-090-G-10-B/4 Replaces the Stauff SE090G10B4
SE-090-G-10-B/4
Stauff
Stauff SE090G10B4
Stauff
Stauff SE090G10B4
Brand:
Stauff
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 90,5 Inner Diameter (mm): 48,5 Length (mm): 164 Sealing: NBR, β ratio >200
Regular price
€93,95
Unit price
per
0.62 kg
8421.99.90
Germany
352
0.8 kg
8421.99.90
United Kingdom
352
0.68 kg
8421.29.80.90
Italy
352
1.76 kg
8421.99.90
Italy
352
0.64 kg
8421.99.90
France
352
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 90,5 Inner Diameter (mm): 48,5 Length (mm): 164 Sealing: NBR, β ratio >200Specification
| Style | Pressure Filter |
| Efficiency 1 | 10µ @ β200 |
| Efficiency 2 | 12µ @ β1000 |
| Outer Diameter | 90.5 mm |
| Inner Diameter | 48.2 mm |
| Length | 162.0 mm |
| Media | Glass Fiber |
| Flow Direction | OUT-IN |
| Δ Collapse Pressure | 20 BAR |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
Genuine Product
