Stauff SE-070-H-03-B/4 Replaces the Stauff SE070H03B
Stauff SE-070-H-03-B/4 Replaces the Stauff SE070H03B
SE-070-H-03-B/4
Stauff
Stauff SE070H03B
Stauff
Stauff SE070H03B
Description
Replacement Filter Element for Pressure Filters Micron Rating: 3 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 69 Inner Diameter (mm): 34,2 Length (mm): 175 Sealing: NBR, β ratio >200
Brand:
Stauff
Regular price
€179,95
Unit price
per
0.79 kg
8421.99.90
Germany
0.76 kg
8421.29.80.90
United States
1.74 kg
8421.99.90
United Kingdom
0.79 kg
8421.99.90
Italy
0.78 kg
8421.99.90
France
Description
Replacement Filter Element for Pressure Filters Micron Rating: 3 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 69 Inner Diameter (mm): 34,2 Length (mm): 175 Sealing: NBR, β ratio >200Specification
| Style | Pressure Filter |
| Efficiency 1 | 3µ @ β200 |
| Efficiency 2 | 5µ @ β1000 |
| Outer Diameter | 69.0 mm |
| Inner Diameter | 34.1 mm |
| Length | 173.0 mm |
| Media | Glass Fiber |
| Flow Direction | OUT-IN |
| Δ Collapse Pressure | 210 BAR |
| Seal Material | Nitrile |
| Temperature Range | -30 - +100°C |
