Specification

StyleAir Filter, Primary Radialseal
FamilyFPG
GenerationRadialSeal™
TypePrimary
MediaCellulose
Efficiency99.9
Test StandardISO 5011
Inner Diameter 105.9 mm
Length 409.5 mm

Description

Why Choose Donaldson RadialSeal™ Filters?

Reliable, leak- resistant Radial Seal™ keeps filters in place – even under heavy vibration.
• High-efficiency cellulose media performs across a wide range of heavy-duty engine applications.
• Corrosion resistant, coated steel liners support media during operation and help maximize airflow.
• Pleatloc™ feature ensures uniform pleat spacing and prevents media from bunching to promote longer service life.

Default Brand Logo

Same Fit-Form & Function

As the Genuine Virgis CH10-15371

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Donaldson Warranty

Donaldson Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
Efficiency 2
Style Air Filter
Outer Diameter
Inner Diameter
Length
Media Type
Flow Direction
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure
Seal
Temperature Range
